Pepperl+Fuchs KFD2-SCD2-Ex2.LK Safety Barriers KFD2-SCD2-Ex2.LK SMART Current Driver
Description of Pepperl+Fuchs KFD2-SCD2-Ex2.LK Safety Barriers KFD2-SCD2-Ex2.LK SMART Current Driver
Smart current driver - 20mm
This isolated barrier is used for intrinsic safety applications. It drives SMART I/P converters, electrical valves, and positioners in hazardous areas.
Digital signals are superimposed on the analog values at the field or control side and are transferred bi-directionally.
Current transferred across the DC/DC converter is repeated at terminals 1, 2 and 4, 5.
An open and shorted field circuit presents a high input impedance to the control side to allow line fault detection by control system.
If the loop resistance for the digital communication is too low, an internal resistor of 250Ω between terminals 8, 9 and 11, 12 is available, which may be used as the HART communication resistor.
Sockets for the connection of a HART communicator are integrated into the terminals of the device.
A unique collective error messaging feature is available when used with the Power Rail system.
Technical specification of Pepperl+Fuchs KFD2-SCD2-Ex2.LK Safety Barriers KFD2-SCD2-Ex2.LK SMART Current Driver
Supply voltage: 10-35V d.c.
Power consumption: 1.8W at 20mA
Input/Output: Analogue output
No. of Channels: 2
Output:
Current: 4-20mA
Load: 100-700Ω
Voltage: ≥14V at 20mA
Input:
Voltage drop: Approx. 4V or internal resistance 200Ω at 20mA
Input resistance: >100kΩ when wiring resistance in the field
<50Ω or >16V (equivalent to 800Ω at 20mA
Current: 4-20mA limited to approx. 25mA
(or the output current if less)
Ambient temperature: -20 to +60°C
Protection rating: IP20
Mounting: 35mm DIN rail or panel mount
Dimensions: w20 x h124 x d115mm
Features of Pepperl+Fuchs KFD2-SCD2-Ex2.LK Safety Barriers KFD2-SCD2-Ex2.LK SMART Current Driver
SMART Current Driver KFD2-SCD2-Ex2.LK
2-channel isolated barrier
24 V DC supply (Power Rail)
Current output up to 700 AZ© load
HART I/P and valve positioner
Line fault detection (LFD)
Accuracy 0.05 %
Terminal blocks with test sockets
Up to SIL2 acc. to IEC 61508
