Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Features of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
For 16 modules
24 V DC supply
Supported signal types: DI/DO/AI/TI/AO
Hazardous area: screw terminals, blue
Non-hazardous area: screw terminals, black
Technical data of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Supply
Connection X20: terminals 3, 5(+); 4, 6(-)
Nominal voltage 24 V DC , in consideration of rated voltage of used isolators
Voltage drop 0.9 V , voltage drop across the series diode on the termination board must be considered
Ripple ≤ 10 %
Fusing 4 A , in each case for 16 modules
Power dissipation ≤ 500 mW , without modules
Reverse polarity protection yes
Redundancy of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Supply Redundancy available. The supply for the isolators is decoupled, monitored and fused.
Fault indication output of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Connection X20: terminals 1, 2
Output type volt-free contact
Switch behaviour no fault: relay contact closed
power supply fault: relay contact open
module fault: relay contact open
Contact loading 30 V DC, 1 A
Indicators/settings of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Display elements LED PWR1 (termination board power supply), green LED
LED PWR2 (termination board power supply), green LED
LED FAULT (fault indication), red LED
- LED lits: module fault
- LED flashes: power supply fault
Directive conformity
Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)
Conformity of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Electromagnetic compatibility NE 21:2017
For further information see system description.
Degree of protection IEC 60529:2001
Ambient conditions of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Ambient temperature -20 ... 60 °C (-4 ... 140 °F)
Storage temperature -40 ... 70 °C (-40 ... 158 °F)
Mechanical specifications of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Degree of protection IP20
Connection
Field side explosion hazardous area: 4 screw terminals per module , blue
Control side non-explosion hazardous area: 4 screw terminals per module , black
Supply pluggable screw terminals , black
Fault output pluggable screw terminals , black
Core cross-section screw terminals: 0.25 ... 1.5 mm2 (24 ... 12 AWG)
Material housing: polycarbonate, 10 % glass fiber reinforced
Mass approx. 980 g
Dimensions 300 x 200 x 163 mm (11.8 x 7.9 x 6.42 inch) , height including module assembly
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001
Data for application in connection with hazardous areas of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
EU-type examination certificate CESI 11 ATEX 062
Marking Ex-Hexagon II (1)G [Ex ia Ga] IIC
Ex-Hexagon II (1)D [Ex ia Da] IIIC
Ex-Hexagon I (M1) [Ex ia Ma] I
Non-hazardous area
Maximum safe voltage 250 V (Attention! Um is no rated voltage.)
Galvanic isolation of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Field circuit/control circuit safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 50303:2000
International approvals of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
CSA approval
Control drawing see control drawing of correspoding modules
IECEx approval
IECEx certificate IECEx CES 11.0022
IECEx marking [Ex ia Ga] IIC
[Ex ia Da] IIIC
[Ex ia Ma] I
General information of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.
Accessories of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
Designation - HART communication board for 1-channel modules: HiATB01-HART-4X8-Y1
- HART communication board for 2-channel modules: HiATB01-HART-2X16
Classifications of Pepperl+Fuchs HiDTB16-SCT-44C-SC-RA Termination Board HiDTB16-SCT-44C-SC-RA Cards 24VDC Supply In Stock
System Classcode
ECLASS 11.0 27210107
ECLASS 10.0.1 27210107
ECLASS 9.0 27210107
ECLASS 8.0 27210107
ECLASS 5.1 27210121
ETIM 8.0 EC001485
ETIM 7.0 EC001485
ETIM 6.0 EC001485
ETIM 5.0 EC001485
UNSPSC 12.1 39121008
