Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
Brief Description of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
Soft starter for asynchronous motor - ATS48 - 195 A - 230..415 V - 45..160 KW
Technical Specification of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
Main of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
range of product Altistart 48
product or component type Soft starter
product destination Asynchronous motors
product specific application Heavy duty industry and pumps
device short name ATS48
power supply voltage 230...415 V - 15...10 %
Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
motor power kW
55 kW at 230 V connection in the motor supply line for standard applications
90 kW at 230 V connection to the motor delta terminals for severe applications
90 kW at 400 V connection in the motor supply line for severe applications
110 kW at 230 V connection to the motor delta terminals for standard applications
110 kW at 400 V connection in the motor supply line for standard applications
132 kW at 400 V connection to the motor delta terminals for severe applications
160 kW at 400 V connection to the motor delta terminals for standard applications
45 kW at 230 V connection in the motor supply line for severe applications
power dissipation in W
468 W for severe applications
580 W for standard applications
utilisation category AC-53A type of start Start with torque control (current limited to 5 In)
Icl nominal current
210 A for connection in the motor supply line for severe applications
210 A for connection in the motor supply line for standard applications
364 A for connection to the motor delta terminals for severe applications
364 A for connection to the motor delta terminals for standard applications
IP degree of protection IP00
Complementary of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
assembly style With heat sink
function available External bypass (optional)
power supply voltage limits 195…456 V
power supply frequency 50...60 Hz - 5...5 %
power supply frequency limits 47.5...63 Hz
device connection
To the motor delta terminals
In the motor supply line
factory setting current 195 A
[Uc] control circuit voltage 220 - 15 % to 415 + 10 %, 50/60 Hz
control circuit consumption 50 W
discrete output number 2
discrete output type
(LO1) logic output 0 V common configurable
(LO2) logic output 0 V common configurable
ATS48C21Q Soft starter for asynchronous motor - ATS48 - 195 A - 230..415 V - 45..160 KW
Main of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
range of product Altistart 48
product or component type Soft starter
product destination Asynchronous motors
product specific application Heavy duty industry and pumps
device short name ATS48
power supply voltage 230...415 V - 15...10 %
motor power kW
55 kW at 230 V connection in the motor supply line for standard applications
90 kW at 230 V connection to the motor delta terminals for severe applications
90 kW at 400 V connection in the motor supply line for severe applications
110 kW at 230 V connection to the motor delta terminals for standard applications
110 kW at 400 V connection in the motor supply line for standard applications
132 kW at 400 V connection to the motor delta terminals for severe applications
160 kW at 400 V connection to the motor delta terminals for standard applications
45 kW at 230 V connection in the motor supply line for severe applications
Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
power dissipation in W
468 W for severe applications
580 W for standard applications
utilisation category AC-53A type of start Start with torque control (current limited to 5 In)
Icl nominal current
210 A for connection in the motor supply line for severe applications
210 A for connection in the motor supply line for standard applications
364 A for connection to the motor delta terminals for severe applications
364 A for connection to the motor delta terminals for standard applications
IP degree of protection IP00
Complementary of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
assembly style With heat sink
function available External bypass (optional)
power supply voltage limits 195…456 V
power supply frequency 50...60 Hz - 5...5 %
power supply frequency limits 47.5...63 Hz
device connection
To the motor delta terminals
In the motor supply line
factory setting current 195 A
[Uc] control circuit voltage 220 - 15 % to 415 + 10 %, 50/60 Hz
control circuit consumption 50 W
discrete output number 2
discrete output type
(LO1) logic output 0 V common configurable
(LO2) logic output 0 V common configurable
(R1) relay outputs fault relay NO
(R2) relay outputs end of starting relay NO
(R3) relay outputs motor powered NO
output absolute accuracy precision
+/- 5 %
minimum switching current
10 mA at 6 V DC for relay outputs
maximum switching current
Logic output 0.2 A at 30 V DC
Relay outputs 1.8 A at 230 V AC inductive load, cos phi = 0.5 20 ms
Relay outputs 1.8 A at 30 V DC inductive load, cos phi = 0.5 20 ms
discrete input number 5
discrete input type PTC, 750 Ohm at 25 °C
(Stop, Run, LI3, LI4) logic, <= 8 mA 4300 Ohm
discrete input voltage 24 V <= 30 V
discrete input logic Positive logic Stop, Run, LI3, LI4 at State 0: < 5 V and <= 2 mA at State 1: > 11 V, >= 5 mA
starting current 0.4...1.3 Icl adjustable
analogue output type Current output AO: 0-20 mA or 4-20 mA, impedance <500 Ohm
communication port protocol Modbus
connector type 1 RJ45
communication data link Serial
physical interface RS485 multidrop
transmission rate 4800, 9600 or 19200 bps
max nodes number 31
protection type
Phase failure: line
Thermal protection: motor
Thermal protection: starter
marking CE
type of cooling Forced convection
operating position Vertical +/- 10 degree
height 380 mm
width 320 mm
depth 265 mm
net weight 18.2 kg
Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
Motor power range AC-3
30…50 kW at 200…240 V 3 phases
55…100 kW at 380…440 V 3 phases
55…100 kW at 200…240 V 3 phases
110…220 kW at 380…440 V 3 phases
110…220 kW at 200…240 V 3 phases
motor starter type Soft starter
Environment of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
electromagnetic compatibility
Conducted and radiated emissions level A conforming to IEC 60947-4-2
Damped oscillating waves level 3 conforming to IEC 61000-4-12
Electrostatic discharge level 3 conforming to IEC 61000-4-2
Immunity to electrical transients level 4 conforming to IEC 61000-4-4
Immunity to radiated radio-electrical interference level 3 conforming to IEC 61000-4-3
Voltage/current impulse level 3 conforming to IEC 61000-4-5
standards
EN/IEC 60947-4-2
product certifications
GOST
SEPRO
CSA
C-Tick
NOM 117
TCF
UL
CCC
DNV
vibration resistance
1 gn (f= 13…200 Hz) conforming to EN/IEC 60068-2-6
1.5 mm (f= 2…13 Hz) conforming to EN/IEC 60068-2-6
shock resistance
15 gn for 11 ms conforming to EN/IEC 60068-2-27
noise level 54 dB
Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
pollution degree Level 3 conforming to IEC 60664-1
relative humidity 0…95 % without condensation or dripping water conforming to EN/IEC 60068-2-3
ambient air temperature for operation
40…60 °C (with current derating of 2 % per °C)
-10…40 °C (without derating)
ambient air temperature for storage -25…70 °C
operating altitude
<= 1000 m without derating
> 1000...2000 m with current derating of 2.2 % per additional 100 m
Packing Units
Unit Type of Package 1 PCE
Number of Units in Package 1 1
Package 1 Weight 21 kg
Package 1 Height 60 cm
Package 1 width 72 cm
Package 1 Length 80 cm
Unit Type of Package 2 S06
Number of Units in Package 2 1
Package 2 Weight 34 kg
Package 2 Height 73.5 cm
Package 2 width 60 cm
Package 2 Length 80 cm
Offer Sustainability of Schneider ATS48C21Q Soft Starters for Asynchronous Motor ATS48 ATS48C21Q Softstarters In Stock
Sustainable offer status Green Premium product
REACh Regulation REACh Declaration
EU RoHS Directive Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration
Mercury free Yes
RoHS exemption information Yes
China RoHS Regulation China RoHS declaration
Environmental Disclosure Product Environmental Profile
Circularity Profile End of Life Information
WEEE
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
