Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
ATS22C17Q soft starter-ATS22-control 220V-power 230V(45kW)/400...440V(90kW)
Technical Specification of Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
Main of Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
Range of product Altistart 22
Product or component
type
Soft starter
Product destination Asynchronous motors
Product specific application
Pumps and fans
Component name ATS22
Phase 3 phase
[Us] rated supply voltage
230...440 V - 15...10 %
Motor power kW 45 KW 230 V
90 KW 400 V
90 kW 440 V
Factory setting current 162 A
Power dissipation in W 91 W for standard applications
Utilisation category AC-53A
Type of start Start with torque control (current limited to 3.5 In)
IcL starter rating 170 A connection in the motor supply line for standard applications
IP degree of protection IP00
Complementary of Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
Assembly style With heat sink
Function available Internal bypass
Supply voltage limits 195…484 V
Supply frequency 50...60 Hz - 10...10 %
Network frequency 45...66 Hz
Device connection To the motor delta terminals
In the motor supply line
[Uc] control circuit voltage 230 V - 15...10 % 50/60 Hz
Control circuit consumption 20 W
Discrete output number 2
Discrete output type Relay outputs R1 230 V running, alarm, trip, stopped, not stopped, starting, ready
C/O
Relay outputs R2 230 V running, alarm, trip, stopped, not stopped, starting, ready
C/O
Minimum switching current 100 mA 12 V DC relay outputs)
Maximum switching current 5 A 250 V AC resistive 1 relay outputs
5 A 30 V DC resistive 1 relay outputs
2 A 250 V AC inductive 0.4 20 ms relay outputs
2 A 30 V DC inductive 7 ms relay outputs
Discrete input number 3
Discrete input type LI1, LI2, LI3) logic, 5 mA 4.3 kOhm
Discrete input voltage 24 V <= 30 V
Discrete input logic Positive logic LI1, LI2, LI3 < 5 V <= 2 mA > 11 V, >= 5 mA
Output current 0.4...1 Icl adjustable
PTC probe input 750 Ohm
Communication port protocol Modbus
Connector type 1 RJ45
Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
Communication data link Serial
Physical interface RS485 multidrop
Transmission rate 4800, 9600 or 19200 bps
Installed device 31
Protection type Phase failure line
Thermal protection motor
Thermal protection starter
Marking CE
Type of cooling Forced convection
Operating position Vertical +/- 10 degree
Height 14.02 in (356 mm)
Width 5.91 in (150 mm)
Depth 9.04 in (229.5 mm)
Net weight 39.68 lb(US) (18 kg)
Motor power range AC-3 30…50 KW 200…240 V 3 phase
55…100 kW 380…440 V 3 phase
Motor starter type Soft starter
Environment of Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
Electromagnetic compatibility Conducted and radiated emissions level A IEC 60947-4-2
Damped oscillating waves level 3 IEC 61000-4-12
Electrostatic discharge level 3 IEC 61000-4-2
Immunity to electrical transients level 4 IEC 61000-4-4
Immunity to radiated radio-electrical interference level 3 IEC 61000-4-3
Voltage/current impulse level 3 IEC 61000-4-5
Standards EN/IEC 60947-4-2
Product certifications CSA
C-Tick
GOST
UL
CCC
Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
Vibration resistance 1 gn 13…200 Hz)EN/IEC 60068-2-6
1.5 mm 2…13 Hz)EN/IEC 60068-2-6
Shock resistance 15 gn 11 ms EN/IEC 60068-2-27
Noise level 56 dB
Pollution degree Level 2 IEC 60664-1
Relative humidity 0…95 % without condensation or dripping water EN/IEC 60068-2-3
Ambient air temperature for operation 14…104 °F (-10…40 °C) without)
104…140 °F (40…60 °C) with current derating 2.2 % per °C)
Ambient air temperature for storage -13…158 °F (-25…70 °C)
Operating altitude <= 3280.84 ft (1000 m) without
> 3280.84...< 6561.68 ft (> 1000...< 2000 m) with current derating of 2.2 % per
additional 100 m
Ordering and shipping details of Schneider Altistart ATS22 ATS22C17Q Soft Starters ATS22C17Q Electric Softstarters In Stock
Category 22576 - ATS22 ALTISTART
Discount Schedule CP1G
GTIN 03606480167263
Package weight(Lbs) 12.67 kg (27.94 lb(US))
Returnability No
Country of origin ID
