Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived

News March 18, 2021

Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived




Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived




Features of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


*   SMART Transmitter Power Supply KFD2-STC4-Ex1.H
*   1-channel isolated barrier
*   24 V DC supply (Power Rail)
*   Input 2-wire and 3-wire SMART transmitters and 2-wire SMART current sources
*   Output 0/4 mA ... 20 mA
*   Terminals with test points
*   High field voltage 17.6 V DC
*   Up to SIL 2 acc. to IEC 61508



Function of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


- This isolated barrier is used for intrinsic safety applications.


- The device supplies 2-wire and 3-wire SMART transmitters with higher output voltage in a hazardous area, and can also be used with 2-wire

SMART current sources.


- It transfers the analog input signal to the safe area as an isolated current value.


- Digital signals may be superimposed on the input signal in the hazardous or safe area and are transferred bi-directionally.


- If the HART communication resistance in the loop is too low, the internal resistance of 250 Ω between terminals 8 and 9 can be used.


- Test sockets for the connection of HART communicators are integrated into the terminals of the device.



Technical data of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Product Description of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived
Input 0/4 mA ... 20 mA
Output 0/4 mA ... 20 mA

General specifications of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived
Signal type Analog input

Functional safety related parameters of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived
Safety Integrity Level (SIL) SIL 2

Supply of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Connection Power Rail or terminals 14+, 15-
Rated voltage 20 ... 35 V DC
Ripple within the supply tolerance
Power dissipation 1.5 W
Power consumption 1.9 W

Input of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Connection side field side
Connection terminals 1+, 2-, 3 or 5-, 6+
Input signal 0/4 ... 20 mA
Voltage drop ≤ 2.4 V at 20 mA (terminals 5, 6)
Input resistance ≤ 64 Ω terminals 2-, 3 ; ≤ 500 Ω terminals 1+, 3 (250 Ω load)
Available voltage ≥ 17.6 V at 20 mA terminals 1+, 3


Output of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived

Connection side control side
Connection terminals 7-, 8+, 9
Load 0 ... 800 Ω at 20 mA
Output signal 0/4 ... 20 mA (overload > 25 mA)
Ripple max. 50 µA rms


Transfer characteristics of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Deviation at 20 °C (68 °F), 0/4 ... 20 mA
≤ 10 µA incl. calibration, linearity, hysteresis, loads and fluctuations of supply voltage
Influence of ambient temperature 0.25 µA/K
Frequency range field side into the control side: bandwidth with 0.5 Vpp signal 0 ... 7.5 kHz (-3 dB)
control side into the field side: bandwidth with 0.5 Vpp signal 0.3 ... 7.5 kHz (-3 dB)
Settling time 200 µs
Rise time/fall time 20 µs


Galvanic isolation of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Output/power supply functional insulation, rated insulation voltage 50 V AC


Indicators/settings of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Display elements LED
Labeling space for labeling at the front


Directive conformity of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Electromagnetic compatibility
Directive 2014/30/EU EN 61326-1:2013 (industrial locations)


Conformity of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Electromagnetic compatibility NE 21:2011
Degree of protection IEC 60529:2001
Protection against electrical shock UL 61010-1:2012


Ambient conditions of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Ambient temperature -20 ... 60 °C (-4 ... 140 °F)


Mechanical specifications of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Degree of protection IP20
Connection screw terminals
Mass approx. 200 g
Dimensions 20 x 124 x 115 mm (0.8 x 4.9 x 4.5 inch) , housing type B2
Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001


Data for application in connection with hazardous areas of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


EU-type examination certificate BAS 99 ATEX 7060 X
Marking Ex-Hexagon II (1)G [Ex ia Ga] IIC , Ex-Hexagon II (1)D [Ex ia Da] IIIC , Ex-Hexagon I (M1) [Ex ia Ma] I
Input [Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I
Supply
Maximum safe voltage 250 V (Attention! The rated voltage can be lower.)
Equipment terminals 1+, 3-
Voltage Uo 27.2 V
Current Io 93 mA
Power Po 632 mW
Internal capacitance Ci 12 nF
Internal inductance Li 0 mH
Equipment terminals 2-, 3
Voltage Ui 30 V
Current Ii 117 mA
Voltage Uo 3.5 V
Current Io 73 mA
Power Po 64 mW
Equipment terminals 1+, 2 / 3-
Voltage Uo 27.2 V
Current Io 117 mA
Power Po 639 mW
Internal capacitance Ci 12 nF
Internal inductance Li 0 mH
Equipment terminals 5-, 6+
Voltage Ui 30 V
Current Ii 117 mA
Voltage Uo 8.7 V
Current Io 0 mA
Internal capacitance Ci 0 nF
Internal inductance Li 0 mH
Output
Maximum safe voltage 250 V (Attention! The rated voltage can be lower.)
Certificate TÜV 99 ATEX 1499 X
Marking Ex-Hexagon II 3G Ex nA II T4 [device in zone 2]
Galvanic isolation
Input/Output safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Input/power supply safe electrical isolation acc. to IEC/EN 60079-11, voltage peak value 375 V
Directive conformity
Directive 2014/34/EU EN 60079-0:2012+A11:2013 , EN 60079-11:2012 , EN 60079-15:2010


International approvals of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


UL approval
Control drawing 116-0428 (cULus)
IECEx approval IECEx BAS 04.0016X
IECEx CML 15.0055X
Approved for [Ex ia Ga] IIC, [Ex ia Da] IIIC, [Ex ia Ma] I
Ex nA IIC T4 Gc


General information of Pepperl+Fuchs KFD2-STC4-Ex1.H SMART Transmitter Power Supply KFD2-STC4-Ex1.H Safety Barriers Brand Orignal New Arrived


Supplementary information Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.
