Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Overview of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Hirschmann MACH102-24TP-FR Fixed-Port Ethernet Switch, 24 x 10/100Base-TX Ports, 2 FE/GE Combo Ports, Redundant 120-240 Power Inputs, 19" Rackmount, Professional Management.
MACH102 switches are intended for basic standalone applications; for backbone applications consider MACH104 switches.
MACH102-24TP-FR - Managed 26-port Fast Ethernet 19" Switch, redundant PSU
26 port Fast Ethernet/Gigabit Ethernet Industrial Workgroup Switch (2 x GE, 24 x FE), managed, Software Layer 2 Professional, Store-and-Forward-Switching, fanless Design, redundant power supply
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Port Type & Quantity
26 ports in total
24x (10/100 BASE-TX, RJ45)
2 Fast Ethernet / Gigabit Combo ports
Features
Software: Layer 2 Professional
Operating voltage: 100 - 240 VAC, 47 - 63 Hz
Redundant Power inputs: 2 x plug-in terminal block, 2-pin
Specification of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Description: 26 port Fast Ethernet/Gigabit Ethernet Industrial Workgroup Switch (2 x GE, 24 x FE), managed, Software Layer 2 Professional, Store-and-Forward-Switching, fanless Design, redundant power supply
Part Number: 943969501
Port type and quantity: 26 ports in total; 24x (10/100 BASE-TX, RJ45) and 2 Gigabit Combo ports
More Interfaces of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Power supply/signaling contact: 1 x plug-in terminal block, 2-pin, output manual or automatic switchable (max. 1 A, 24 V DC bzw. 24 V AC)
V.24 interface: 1 x RJ11 socket, serial interface for device configuration
USB interface: 1 x USB to connect auto-configuration adapter ACA21-USB
Network size - length of cable of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Twisted pair (TP): 0-100 m
Single mode fiber (SM) 9/125 µm: Fast Ethernet: see SFP LWL module M-FAST SFP-SM/LC and M-FAST SFP-SM+/LC; Gigabit Ethernet: see SFP LWL module M-SFP-LX/LC
Single mode fiber (LH) 9/125 µm (long haul transceiver): Fast Ethernet: see SFP LWL module M-FAST SFP-LH/LC; Gigabit Ethernet: see SFP LWL module M-SFP-LH/LC and M-SFP-LH+/LC
Multimode fiber (MM) 50/125 µm: Fast Ethernet: see SFP LWL module M-FAST SFP-MM/LC; Gigabit Ethernet: see SFP LWL module M-SFP-SX/LC and M-SFP-LX/LC
Multimode fiber (MM) 62.5/125 µm: Fast Ethernet: see SFP LWL module M-FAST SFP-MM/LC; Gigabit Ethernet: see SFP LWL module M-SFP-SX/LC and M-SFP-LX/LC
Network size - cascadibility of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Line - / star topology: any
Ring structure (HIPER-Ring) quantity switches: 50 (reconfiguration time 0.3 sec.)
Power requirements of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Operating Voltage: 100 - 240 VAC, 47 - 63 Hz (redundant)
Power consumption: 17 W
Power output in BTU (IT)/h: 58
Redundancy functions: HIPER-ring (ring structure), MRP (IEC-ring functionality), RSTP 802.1D-2004, redundant network/ring coupling, dual homing, link aggregation, redundant 100 - 240 VAC power supply
Software of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Switching: Disable Learning (hub functionality), Independent VLAN Learning, Fast Aging, Static Unicast/Multicast Address Entries, QoS / Port Prioritization (802.1D/p), TOS/DSCP Prioritization, Egress Broadcast Limiter per Port, Flow Control (802.3X), VLAN (802.1Q), GARP VLAN Registration Protocol (GVRP), Double VLAN Tagging (QinQ), Voice VLAN, GARP Multicast Registration Protocol (GMRP), IGMP Snooping/Querier (v1/v2/v3)
Redundancy: Advanced Ring Configuration for MRP, HIPER-Ring (Manager), HIPER-Ring (Ring Switch), Fast HIPER-Ring, Link Aggregation with LACP, Media Redundancy Protocol (MRP) (IEC62439-2), Redundant Network Coupling, RSTP 802.1D-2004 (IEC62439-1), MSTP (802.1Q), RSTP Guards
Management: Dual Software Image Support, TFTP, LLDP (802.1AB), LLDP-MED, SSHv1, SSHv2, V.24, HTTP, HTTPS, Traps, SNMP v1/v2/v3, Telnet
Diagnostics: Management Address Conflict Detection, Address Relearn Detection, MAC Notification, Signal Contact, Device Status Indication, TCPDump, LEDs, Syslog, Port Monitoring with Auto-Disable, Link Flap Detection, Overload Detection, Duplex Mismatch Detection, Link Speed and Duplex Monitoring, RMON (1,2,3,9), Port Mirroring 1:1, Port Mirroring 8:1, Port Mirroring N:1, System Information, Self-Tests on Cold Start, Copper Cable Test, SFP Management, Configuration Check Dialog, Switch Dump
Configuration: AutoConfiguration Adapter ACA11 Limited Support (RS20/30/40, MS20/30), Automatic Configuration Undo (roll-back), Configuration Fingerprint, BOOTP/DHCP Client with Auto-Configuration, DHCP Server: per Port, DHCP Server: Pools per VLAN, DHCP Server: Option 43, AutoConfiguration Adapter ACA21/22 (USB), HiDiscovery, DHCP Relay with Option 82, Command Line Interface (CLI), CLI Scripting, Full-featured MIB Support, Web-based Management, Context-sensitive Help
Security: IP-based Port Security, MAC-based Port Security, Port-based Access Control with 802.1X, Guest/unauthenticated VLAN, RADIUS VLAN Assignment, Multi-Client Authentication per Port, MAC Authentication Bypass, Access to Management restricted by VLAN, HTTPS Certificate Management, Restricted Management Access, Appropriate Use Banner, SNMP Logging, Local User Management, Remote Authentication via RADIUS
Time synchronisation: Buffered Real Time Clock, SNTP Client, SNTP Server
Industrial Profiles: EtherNet/IP Protocol, PROFINET IO Protocol
Miscellaneous: Manual Cable Crossing
Ambient conditions of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MTBF (MIL-HDBK 217F: Gb 25 ºC): 14.93 Years
Operating temperature: 0-+50 °C
Storage/transport temperature: -20-+85 °C
Relative humidity (non-condensing): 10-95 %
Mechanical construction of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Dimensions (WxHxD): 448 mm x 44 mm x 310 mm (without fixing bracket)
Weight: 4.10 kg
Mounting: 19" control cabinet
Protection class: IP20
EMC interference immunity of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
EN 61000-4-2 electrostatic discharge (ESD): 4 kV contact discharge, 8 kV air discharge
EN 61000-4-3 electromagnetic field: 10 V/m (80-2700 MHz)
EN 61000-4-4 fast transients (burst): 2 kV power line, 4 kV data line
EN 61000-4-5 surge voltage: power line: 2 kV (line/earth), 1 kV (line/line), 4 kV data line
EN 61000-4-6 Conducted Immunity: 10 V (150 kHz-80 MHz)
EMC emitted immunity
EN 55022: EN 55022 Class A
FCC CFR47 Part 15: FCC 47CFR Part 15, Class A
Approvals of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Safety of industrial control equipment: cUL 508
Safety of information technology equipment: cUL 60950-1
Scope of delivery and accessories of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Accessories to Order Separately: Fast Ethernet SFP modules, Gigabit Ethernet SFP modules, autoConfiguration Adapter ACA21-USB, terminal cable, Industrial Hivision Network Management software
Scope of delivery: MACH100 device, terminal block for signal contact, 2 brackets with fasteningscrews (pre-assembled), housing feet - stick-on, non-heating appliance cable - Euro model
Ordering Codes of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MACH102-24TP-F
MACH102-24TP-FR
MACH102-24TP-F
MACH102-24TP-FR
MACH102-8TP
MACH102-8TP-F
MACH102-8TP-FR
MACH102-8TP-R
MACH104-20TX-F
MACH104-20TX-FR
MACH104-20TX-F-4PoE
MACH104-16TX-PoEP
MACH104-16TX-PoEP-R
MACH104-16TX-PoEP-E
MACH104-16TX-PoEP+2X
MACH104-16TX-PoEP+2X-R
MACH104-16TX-PoEP+2X-E
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
M1-8MM-SC
M1-8SFP
M1-8SM-SC
M1-8TP-RJ45
M1-8TP-RJ45 PoE
MACH4002 48+4G-L2P
MACH4002 48+4G-L3E
MACH4002 48+4G-L3P
MACH4002-24G-L2P
MACH4002-24G-L3E
MACH4002-24G-L3P
MACH4002-24G+3X-L2P
MACH4002-24G+3X-L3E
MACH4002-24G+3X-L3P
MACH4002-48G-L2P
MACH4002-48G-L3E
MACH4002-48G-L3P
MACH4002-48G+3X-L2P
MACH4002-48G+3X-L3E
MACH4002-48G+3X-L3P
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
M4-8TP-RJ45
M4-FAST 8-SFP
M4-FAST 8TP-RJ45-PoE
M4-GIGA 8-SFP
M4-AIR
M4-S-AC/DC 300W
M4-S-24VDC 300W
M4-S-48VDC 300W
M4-POWER
M4-P AC/DC
M4-P DC 24V
M4-P DC 48V
M4-POWERCABLE
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MACH102-8TP
MACH102-8TP-R
M1-8TP-RJ45
M1-8MM-SC
M1-8SM-SC
M1-8SFP
M1-8TP-RJ45 PoE
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MACH102-8TP-F
MACH102-8TP-FR
MACH102-24TP-F
MACH102-24TP-FR
MACH104-20TX-F
MACH104-20TX-FR
MACH104-20TX-F-4PoE
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MACH102-24TP-F
MACH102-24TP-FR
MACH102-8TP
MACH102-8TP-F
MACH102-8TP-FR
MACH102-8TP-R
MACH104-20TX-F
MACH104-20TX-FR
MACH104-20TX-F-4PoE
MACH104-16TX-PoEP
MACH104-16TX-PoEP-R
MACH104-16TX-PoEP-E
MACH104-16TX-PoEP+2X
MACH104-16TX-PoEP+2X-R
MACH104-16TX-PoEP+2X-E
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
M1-8MM-SC
M1-8SFP
M1-8SM-SC
M1-8TP-RJ45
M1-8TP-RJ45 PoE
MACH4002 48+4G-L2P
MACH4002 48+4G-L3E
MACH4002 48+4G-L3P
MACH4002-24G-L2P
MACH4002-24G-L3E
MACH4002-24G-L3P
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTSG9HP
MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTSGGHP
MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTUG9HP
MAR1020-99MMTTTTTTTTTTTTTTTTTTTTTTUGGHP
MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTSG9HP
MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTSGGHP
MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUC9HP
MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUCCHP
MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUCGHP
MAR1020-99TTTTTTTTTTTTTTTTTTTTTTTTUG9HP
MAR1020-99ZZTTTTTTTTTTTTTTTTTTTTTTUGGHP
MAR1020-99ZZZZTTTTTTTTTTTTTTTTTTTTUGGHP
MAR1120-99NNTTTTTTTTTTTTTTTTTT9999FMMHP
MAR1122-99TTTTTTTTTTTTZZZZZZZZ9999UMMHP
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MAR1030-4OTTTTTTTTTTTTTTTT99999999SMMHP
MAR1030-4OTTTTTTTTTTTTTTTTTTTTTTTTSG9HP
MAR1030-CCTTTTTTTTTTTTTTTTNNNNNNNNUGGHP
MAR1030-CCTTTTTTTTTTTTTTTTTTTTMMMMSGGHP
MAR1030-CCTTTTTTTTTTTTTTTTTTTTMMMMUGGHP
MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSG9HP
MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTSGGHP
MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUG9HP
MAR1030-CCTTTTTTTTTTTTTTTTTTTTTTTTUGGHP
MAR1030-CCVVTTTTTTTTTTTTTTTTTTTTTTUC9HP
MAR1030-CCVVVVTTTTTTTTTTTTTTTTTTTTSGGHP
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MS4128-L2P 943 009-002 Layer 2/Professional 28 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x any MM4(max 28 ports)
MS4128-L2P EEC 943 009-103 Layer 2/Professional 28 Same as 002 except extended temperature range
MS4128-L3E 943 009-202 Layer 3/Enhanced 28 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x any MM4(max 28 ports)
MS4128-L3E EEC 943 009-203 Layer 3/Enhanced 28 Same as 202 except extended temperature range
MS4128-L3P 943 009-302 Layer 3/Professional 28 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x any MM4(max 28 ports)
MS4128-L3P EEC 943 009-303 Layer 3/Professional 28 Same as 302 except extended temperature range
MS Modules: Maximum Module Density of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MS20-08 2 x any MM2/MM3
MS20-16 4 x any MM2/MM3 (6 x using MB-2T backplane extension)
MS30-08 2 x any MM2/MM3 plus 1 x MM4-2TX/SFP
MS30-16 4 x any MM2/MM3 (6 x using MB-2T backplane extension), plus 1 x MM4-2TX/SFP
MS4128 4 x any MM2/MM3 (6 x using MB-2T backplane extension), plus 1 x any MM4
MS Modules: ALL COPPER of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Type Part No. Order No. Ports/Speed
ALL COPPER MM2-4TX1 943 722-101 4 x 10/100 Mbps RJ45
ALL COPPER MM2-4TX1-EEC 943 722-151 4 x 10/100 Mbps RJ45, ext. temperature range*
MS Managed Modular DIN Rail Mount Switches of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MS Modules: MULTIMODE of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
MM MM2-2FXM2 943 718-101 2 x 100 Mbps MM SC
MM MM3-4FXM2 943 764-101 4 x 100 Mbps MM SC
MM MM3-4FXM4 943 835-101 4 x 100 Mbps MM ST
MM MM3-1FXM2/3TX1 943 839-101 1 x 100 Mbps MM SC, 3 x RJ45
MM MM3-2FXM4/2TX1 943 837-101 2 x 100 Mbps MM ST, 2 x RJ45
MM MM3-4FLM4 943 760-101 4 x 10 Mbps MM ST
MM MM3-2FXM2/2TX1 943 761-101 2 x 100 Mbps MM SC, 2 x RJ45
MM MM3-2FXM2/2TX1-EEC 943 761-151 2 x 100 Mbps MM SC, 2 x RJ45, ext. temperature range*
MM MM3-1FXM2/1FXS2/2TX1 943 929-101 2 x 100 Mbps SC (1 x MM and 1 x SM), 2 x RJ45
MM MM2-4FXM3 943 721-101 4 x 100 Mbps MM MTRJ
MM MM2-2FXM3/2TX1 943 720-101 2 x 100 Mbps MM MTRJ, 2 x RJ45
SFP MM20-Z6Z6Z6Z6SAHH 943 938-001 4 x 100 Mbps SFP sockets (SFPs need to be purchased separately), for MS20, MS30 and MS4128
MS Modules: SINGLEMODE of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Type Part No. Order No. Ports/Speed
SM MM 2-2FXS2 943 719-101 2 x 100 Mbps SM SC
SM MM 3-2FXS2/2TX1 943 762-101 2 x 100 Mbps SM SC, 2 x RJ45
SM MM 3-2FXS2/2TX1-EEC 943 762-151 2 x 100 Mbps SM SC, 2 x RJ45, ext. temp.*
SM MM 3-1FXS2/3TX1 943 838-101 1 x 100 Mbps SM SC, 3 x RJ45
SM MM 3-4FXS2 943 836-101 4 x 100 Mbps SM SC
SM MM 3-1FXL2/3TX1 943 763-101 1 x 100 Mbps SM, SC Long Haul, 3 x RJ45
SM MM3-1FXLH+/3TX1 943 930-101 1 x 100 Mbps SM SC Long Haul+, 3 x RJ45
SM MM 3-1FXS2/3TX1-EEC 943 838-151 1 x 100 Mbps SM SC, 3 x RJ45, ext. temp.*
SFP MM20-Z6Z6Z6Z6SAHH 943 938-001 4 x 100 Mbps SFP sockets (SFPs need to be purchased separately), for MS20, MS30 and MS4128
MS Modules: GIGABIT of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Type Part No. Order No. Ports/Speed
GIGABIT MM 4-2TX/SFP 943 622-001 2 x Gigabit RJ45/SFP combo ports** for use with MS30 and MS4128
GIGABIT MM 4-4TX/SFP 943 010-001 4 x Gigabit RJ45/SFP combo ports** for use with MS4128 only
MS Modules: SPECIAL PURPOSE of Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
Type Part No. Order No. Ports/Speed
REALTIME MM23-T1T1T1T1SA PTP IEEE1588 Version 2 realtime module, 4x 10/100 RJ45, replacement for 943 117-001
REALTIME MM23-M2M2T1T1SA PTP IEEE1588 Version 2 realtime module, 2x multimode, SC sockets, replacement for 943 117-002
REALTIME MM23-S2S2T1T1SA PTP IEEE1588 Version 2 realtime module, 2x singlemode, SC sockets, replacement for 943 117-003
REALTIME MM23-F4F4T1T1SA PTP IEEE1588 Version 2 realtime module, 2x multimode, ST sockets, replacement for 943 117-004
REALTIME MM33-O7O79999SA PTP IEEE1588 Version 2 realtime module, SFP sockets
REALTIME MM3-4TX1-RT-EEC 943 955-001 4 x RJ45, railway certifications EN 50155, EN 50121-4
REALTIME MM3-2FXM2/2TX1-RT-EEC 943 955-002 2 x 100 Mbps MM SC, 2 x RJ45, IEEE 1588, railway certifications EN 50155, EN 50121-4
REALTIME MM3-2FXS2/2TX1-RT-EEC 943 955-003 2 x 100 Mbps SM SC, 2 x RJ 45, IEEE 1588, railway certifications EN 50155, EN 50121-4
AUI MM3-2AUI 943 840-101 2 x AUI SUB-D 15-pin male D-sub
IP67 MM3-4TX5 943 841-101 4 x M12 socket (D-code), for connectors see OCTOPUS family
POE MM22-T1T1T1T1SAHH 943 938-002 4 x RJ45 PoE (external PoE power supply)
SFP MM20-Z6Z6Z6Z6SAHH 943 938-001 4 x 100 Mbps SFP sockets (SFPs need to be purchased separately), for MS20, MS30 and MS4128
Hirshcmann MACH102-24TP-FR Ethernet Switches MACH102-24TP-FR Industrial Rail Switches In Stock
We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.
We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.
Contact:
HONGKONG XIEYUAN TECH CO., LIMITED
Email:becky@hkxytech.com Web:www.hkxytech.com
Mobile:+86-15972186287(Whatsapp & Wechat)
