Yokogawa SC4AJ-S-AD-09-010-10-T1/PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1/PS Industrial Sensors In Stock
Overview of Yokogawa SC4AJ-S-AD-09-010-10-T1/PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1/PS Industrial Sensors In Stock
Now, Yokogawa provides the FLXA402 four-wire conductivity/resistivity converter, the FLXA202 and FLXA21 two-wire conductivity/resistivity transmitters. Yokogawa also provides many kinds of sensors for accurately measuring liquid conductivity when using converters/transmitters.
The combination of Yokogawa's converters/transmitter and sensors meets the demanding ultrapurewater requirements of the growing semiconductor and pharmacentical markets in addition to traditional water quality measurements for standard power plant and chemical applications.
The SC4AJ conductivity sensor has a convenient, compact design and is widely used in various applications including boiler water and hydroponics conductivity measurement and pure water resistivity measurement in the semiconductor, food, pharmaceutical, and power industries.
Specifications of Yokogawa SC4AJ-S-AD-09-010-10-T1PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1PS Industrial Sensors In Stock
Object of measurement Conductivity of liquids or solutions
Measuring principle Two-electrode system
Cell constant 0.02 cm-1, 0.1cm-1
Measuring range 0 - 0.5 to 0 - 200 μS/cm (Cell constant: 0.02 cm-1)
(with SC450G, SC202)
0 - 100 μS/cm to 0 - 1 mS/cm (Cell constant: 0.02 cm-1)
(with SC100)
0 - 5 μS/cm to 0 - 1 mS/cm (Cell constant: 0.1 cm-1)
(with SC450G, SC202)
0 - 500 μS/cm to 0 - 5 mS/cm (Cell constant: 0.1 cm-1)
(with SC100; Material: Titanium)
Yokogawa SC4AJ-S-AD-09-010-10-T1PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1PS Industrial Sensors In Stock
Temperature Range 0 to 110℃ (For electrode)
Sterilization for electrode 135℃ (275℉), within 30 minutes in Steam Sterilization
Pressure range 0 to 1 MPa (For electrode)
Sample solution condition Although flow rate is not limited in measurement, air bubbles should not be mixed in the sample solutions to obtain correct measured values.
Temperature sensor Pt1000
Yokogawa SC4AJ-S-AD-09-010-10-T1PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1PS Industrial Sensors In Stock
Adapter mounting type (SC4AJ-S-AD-09-002-05): approx. 450 g
Adapter mounting type (SC4AJ-S-AD-15-002-05): approx. 520 g
Welding socket type (SC4AJ-S-SA-NN-002-05): approx. 670 g
5" welding clamp type (SC4AJ-S-SB-NN-002-05): approx. 550 g
2" welding clamp type (SC4AJ-S-SC-NN-002-05): approx. 670 g
Adapters:
3/4" stainles steel adapter (/PS): approx. 110 g
3/4" PVDF adapter (/PF) : approx. 35 g
Straight welding socket (/SA1) : approx. 300 g
Angle welding socket 15 (/SA2) : approx. 320 g
Welding clamp 1" (/SB1) : approx. 330 g
Welding clamp 1.5" (/SB2) : approx. 305 g
Welding clamp 2" (/SC1) : approx. 350 g
Process connection Adapter mounting, welding socket, welding clamp
GENERAL SPECIFICATIONS of Yokogawa SC4AJ-S-AD-09-010-10-T1PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1PS Industrial Sensors In Stock
SC4AJ:
Cable with pin terminals (applicable to FLXA202,FLXA21, FLXA402)
Cable with M4 ring terminals (applicable to FLXA202,FLXA21)
Cable with M3 ring terminals (applicable to FLXA402)
Variopin connector (applicable to SA11)
Object of measurement: Conductivity of solutions
Measuring principle: Two-electrode system
Cell constant: 0.02 cm-1, 0.1 cm-1
Yokogawa SC4AJ-S-AD-09-010-10-T1PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1PS Industrial Sensors In Stock
Measuring range:
For a cell constant: 0.02 cm-1:
0-0.5 µS/cm to 0-200 µS/cm
For a cell constant: 0.1 cm-1:
0-5 µS/cm to 1 mS/cm
Temperature Range: For electrode, 0 to 110°C
For holder, see Figure 1
Sterilization for electrode:
135°C (275°F), within 30 minutes in
Steam Sterilization
Pressure range : For electrode, 0 to 1 MPa
For holder, see Figure 1
Ordering Information of Yokogawa SC4AJ-S-AD-09-010-10-T1PS Conductivity Sensors SC4AJ-S-AD-09-010-10-T1PS Industrial Sensors In Stock
Model Sufx Code Option Code Description
SC4AJ .............................................Conductivity sensor
Material -T.......................Titanium (Only for -AD)
-S.......................316L SS
Fitting type -AD.......................Adapter mounting type
-SA.......................Welding socket type (*1)
-SB.......................1 or 1.5 inch welding clamp type (*2)
-SC.......................2 inch welding clamp type (*2)
Sensor length -09.......................9 cm (Code for -AD)
-15.......................15 cm (Code for -AD)
-NN.......................fixed length (Code for -SA, -SB, -SC)
Cell constant -002.......................0.02 cm-1
-010.......................0.1 cm-1
Cable length -03.......................3 m (pin terminals)
-05.......................5 m (pin terminals)
-10.......................10 m (pin terminals)
-15.......................15 m (pin terminals)
-20.......................20 m (pin terminals)
-X1.......................3 m (M4 ring terminals) (*4)
-X2.......................5 m (M4 ring terminals) (*4)
-X3.......................10 m (M4 ring terminals) (*4)
-X4.......................15 m (M4 ring terminals) (*4)
-X5.......................20 m (M4 ring terminals) (*4)
-Y1.......................3 m (M3 ring terminals) (*4)
-Y2.......................5 m (M3 ring terminals) (*4)
-Y3.......................10 m (M3 ring terminals) (*4)
-Y4.......................15 m (M3 ring terminals) (*4)
-Y5.......................20 m (M3 ring terminals) (*4)
-VS.......................Variopin connector (*6)
Temperature sensor -T1 ....................... Pt1000
Option For AD only /PS 3/4NPT adapter 316 SS
/PF 3/4NPT adapter PVDF
/RS R3/4 adapter 316 SS
/RF R3/4 adapter PVDF
For SA only /SA1 Straight welding socket 316L SS
/SA2 Angled welding socket 15° 316L SS
For SB only /SB1 Welding clamp 1 inch 316L SS
/SB2 Welding clamp 1.5 inch 316L SS
For SC only /SC1 Welding clamp 2 inch 316L SS
Oil prohibit /DG1 Oil-prohibited use (*3)
