Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Hirschmann RS30-1602OOZZSDAE  RS30-1602OOZZSDAEHHXX.X.

Overview of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Description 18 port Gigabit/Fast-Ethernet-Switch (2 x Gigabit Ethernet, 16 x Fast Ethernet), managed, software Layer 2 Enhanced, for DIN rail store-and-forward-switching, fanless design

Port type and quantity 18 Ports in total, 2 Gigabit Ethernet ports; 1. uplink: 2 x Fast Ethernet/Gigabit Ethernet SFP-Slot; 2. uplink: 2 x Fast Ethernet SFP-slot; 14 x standard 10/100 BASE TX, RJ45

Type RS30-1602OOZZSDAEHH09.0.

Order No. RS30-1602OOZZSDAEHH09.0.

More Interfaces of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Power supply/signaling contact 1 x plug-in terminal block, 6-pin

V.24 interface 1 x RJ11 socket

USB interface 1 x USB to connect the AutoConfiguration Adapter ACA21-USB

Network size - length of cable of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Multimode fiber (MM) 50/125 µm cf. SFP LWL module M-SFP-SX/LC and M-SFP-LX/LC

Multimode fiber (MM) 62.5/125 µm cf. SFP LWL module M-SFP-SX/LC and M-SFP-LX/LC

Single mode fiber (SM) 9/125 µm cf. SFP LWL module M-SFP-LX/LC

Single mode fiber (LH) 9/125 µm (long haul transceiver) cf. SFP LWL module M-SFP-LH/LC und M-SFP-LH+/LC

Network size - cascadibility of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Line - / star topology any

Ring structure (HIPER-Ring) quantity switches 50 (reconfiguration time < 0.3 sec.)

Power requirements of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Operating voltage 12/24/48 V DC (9,6-60) V and 24 V AC (18-30) V (redundant)

Current consumption at 24 V DC 516 mA

Current consumption at 48 V DC 257 mA

Power output in Btu (IT) h 40.4

Software of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Management TFTP; LLDP (802.1AB); V.24; HTTP; Traps; SNMP v1/v2/v3; Telnet

Diagnostics Management Address Conflict Detection; Address Relearn Detection; Signal Contact; Device Status Indication; LEDs; Syslog; Duplex Mismatch Detection; RMON (1,2,3,9); Port Mirroring 1:1; Port Mirroring 8:1; System Information; Self-Tests on Cold Start; SFP Management; Switch Dump

Configuration AutoConfiguration Adapter ACA11 Limited Support (RS20/30/40, MS20/30); Automatic Configuration Undo (roll-back); Configuration Fingerprint; BOOTP/DHCP Client with Auto-Configuration; AutoConfiguration Adapter ACA21/22 (USB); HiDiscovery; DHCP Relay with Option 82; Command Line Interface (CLI); Full-featured MIB Support; Web-based Management; Context-sensitive Help

Security IP-based Port Security; MAC-based Port Security; Access to Management restricted by VLAN; SNMP Logging; Local User Management

Redundancy functions HIPER-Ring (Manager); HIPER-Ring (Ring Switch); Media Redundancy Protocol (MRP) (IEC62439-2); Redundant Network Coupling; RSTP 802.1D-2004 (IEC62439-1); RSTP Guards; RSTP over MRP

Industrial Profiles EtherNet/IP Protocol; PROFINET IO Protocol

Time synchronisation SNTP server and client

Miscellaneous Manual Cable Crossing

Switching Disable Learning (hub functionality); Independent VLAN Learning; Fast Aging; Static Unicast/Multicast Address Entries; QoS / Port Prioritization (802.1D/p); TOS/DSCP Prioritization; Egress Broadcast Limiter per Port; Flow Control (802.3X); VLAN (802.1Q); IGMP Snooping/Querier (v1/v2/v3)

Ambient conditions of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Operating temperature 0 ºC ... 60 ºC

Storage/transport temperature -40 ºC ... 70 ºC

Relative humidity (non-condensing) 10 % ... 95 %

MTBF 39.7 years (MIL-HDBK-217F)

Protective paint on PCB No

Mechanical construction of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Dimensions (W x H x D) 110 mm x 131 mm x 111 mm

Mounting DIN Rail

Protection class IP20

Mechanical stability of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

IEC 60068-2-27 shock 15 g, 11 ms duration, 18 shocks

IEC 60068-2-6 vibration 1 mm, 2 Hz-13.2 Hz, 90 min.; 0.7 g, 13.2 Hz-100 Hz, 90 min.; 3.5 mm, 3 Hz-9 Hz, 10 cycles, 1 octave/min.; 1 g, 9 Hz-150 Hz, 10 cycles, 1 octave/min

EMC interference immunity of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

EN 61000-4-2 electrostatic discharge (ESD) 6 kV contact discharge, 8 kV air discharge

EN 61000-4-3 electromagnetic field 10 V/m (80-1000 MHz)

EN 61000-4-4 fast transients (burst) 2 kV power line, 1 kV data line

EN 61000-4-5 surge voltage power line: 2 kV (line/earth), 1 kV (line/line), 1 kV data line

EN 61000-4-6 conducted immunity 3 V (10 kHz-150 kHz), 10 V (150 kHz-80 MHz)

EMC emitted immunity of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

FCC CFR47 Part 15 FCC 47 CFR Part 15 Class A

EN 55022 EN 55022 Class A

Approvals of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Safety of industrial control equipment cUL 508

Hazardous locations ISA 12.12.01 Class 1 Div. 2

Shipbuilding n/a

Railway norm n/a

Substation n/a

All Copper of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400T1T1SDAE 943 434-007 4 x RJ45

RS20-0400T1T1SDAP 943 434-008 4 x RJ45

RS20-0800T1T1SDAE 943 434-021 8 x RJ45

RS20-0800T1T1SDAP 943 434-022 8 x RJ45

RS20-1600T1T1SDAE 943 434-023 16 x RJ45

RS20-1600T1T1SDAP 943 434-024 16 x RJ45

RS20-2400T1T1SDAE 943 434-041 24 x RJ45

RS20-2400T1T1SDAP 943 434-042 24 x RJ45

Multimode of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400M2T1SDAE 943 434-009 3 x RJ45, 1 x SC

RS20-0400M2T1SDAP 943 434-010 3 x RJ45, 1 x SC

RS20-0400M2M2SDAE 943 434-001 2 x RJ45, 2 x SC

RS20-0400M2M2SDAP 943 434-002 2 x RJ45, 2 x SC

RS20-0800M2M2SDAE 943 434-003 6 x RJ45, 2 x SC

RS20-0800M2M2SDAP 943 434-004 6 x RJ45, 2 x SC

RS20-0800M4M4SDAE 943 434-017 6 x RJ45, 2 x ST

RS20-0800M4M4SDAP 943 434-018 6 x RJ45, 2 x ST

RS20-1600M2T1SDAE 943 434-025 15 x RJ45, 1 x SC

RS20-1600M2T1SDAP 943 434-026 15 x RJ45, 1 x SC

RS20-1600M2M2SDAE 943 434-005 14 x RJ45, 2 x SC

RS20-1600M2M2SDAP 943 434-006 14 x RJ45, 2 x SC

RS20-2400M2M2SDAE 943 434-043 22 x RJ45, 2 x SC

RS20-2400M2M2SDAP 943 434-044 22 x RJ45, 2 x SC

Single-Mode of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400S2T1SDAE 943 434-011 3 x RJ45, 1 x SC

RS20-0400S2T1SDAP 943 434-012 3 x RJ45, 1 x SC

RS20-0400S2S2SDAE 943 434-013 2 x RJ45, 2 x SC

RS20-0400S2S2SDAP 943 434-014 2 x RJ45, 2 x SC

RS20-0800S2S2SDAE 943 434-019 6 x RJ45, 2 x SC

RS20-0800S2S2SDAP 943 434-020 6 x RJ45, 2 x SC

RS20-1600S2S2SDAE 943 434-027 14 x RJ45, 2 x SC

RS20-1600S2S2SDAP 943 434-028 14 x RJ45, 2 x SC

RS20-2400S2S2SDAE 943 434-045 22 x RJ45, 2 x SC

RS20-2400S2S2SDAP 943 434-046 22 x RJ45, 2 x SC

All Copper of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS30-0802T1T1SDAE 943 434-029 8 x 10/100 RJ45,2 x 10/100/1000 RJ45

RS30-0802T1T1SDAP 943 434-030 8 x 10/100 RJ45,2 x 10/100/1000 RJ45

RS30-1602T1T1SDAE 943 434-033 16 x 10/100 RJ45,2 x 10/100/1000 RJ45

RS30-1602T1T1SDAP 943 434-034 16 x 10/100 RJ45,2 x 10/100/1000 RJ45

RS30-2402T1T1SDAE 943 434-037 24 x 10/100 RJ45,2 x 10/100/1000 RJ45

RS30-2402T1T1SDAP 943 434-038 24 x 10/100 RJ45,2 x 10/100/1000 RJ45

Fiber of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS30-0802O6O6SDAE 943 434-031 8 x 10/100 RJ45,2 x Gigabit SFP

RS30-0802O6O6SDAP 943 434-032 8 x 10/100 RJ45,2 x Gigabit SFP

RS30-1602O6O6SDAE 943 434-035 16 x 10/100 RJ45,2 x Gigabit SFP

RS30-1602O6O6SDAP 943 434-036 16 x 10/100 RJ45,2 x Gigabit SFP

RS30-2402O6O6SDAE 943 434-039 24 x 10/100 RJ45,2 x Gigabit SFP

RS30-2402O6O6SDAP 943 434-040 24 x 10/100 RJ45,2 x Gigabit SFP

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0800M2M2SDAP RS20-0800M4M4SDAE RS20-0800M4M4SDAP RS20-0800T1T1SDAE RS20-1600T1T1SDAU RS20-1600T1T1SDAP RS20-1600S2S2SDAE RS20-0800S2S2TDHE RSR30-0802S2M2T1UCCHPHH04.0

Ordering Information of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

All Copper of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RSB20-0800T1T1SAAB 942 014 001 8 8TX

RSB20-0800T1T1SAABE 942 014 017 8 8TX E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0800T1T1TAABE 942 014 025 8 8TX E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0800T1T1TAAB 942 014 009 8 8TX EEC

Multimode (Copper & Fiber) of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RSB20-0800M2M2SAAB 942 014 002 8 6TX/2FX MM

RSB20-0800M2M2SAABE 942 014 018 8 6TX/2FX MM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0800M2M2TAABE 942 014 026 8 6TX/2FX MM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0800M2M2TAAB 942 014 010 8 6TX/2FX MM EEC

RSB20-0900M2TTSAAB 942 014 005 9 8TX/1FX MM

RSB20-0900M2TTSAABE 942 014 021 9 8TX/1FX MM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900M2TTTAABE 942 014 029 9 8TX/1FX MM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900M2TTTAAB 942 014 013 9 8TX/1FX MM EEC

RSB20-0900MMM2SAAB 942 014 007 9 6TX/3FX MM

RSB20-0900MMM2SAABE 942 014 023 9 6TX/3FX MM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900MMM2TAABE 942 014 031 9 6TX/3FX MM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900MMM2TAAB 942 014 015 9 6TX/3FX MM EEC

Singlemode (Copper & Fiber) of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RSB20-0800S2S2SAAB 942 014 003 8 6TX/2FX SM

RSB20-0800S2S2SAABE 942 014 019 8 6TX/2FX SM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0800S2S2TAABE 942 014 027 8 6TX/2FX SM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0800S2S2TAAB 942 014 011 8 6TX/2FX SM EEC

RSB20-0900S2TTSAAB 942 014 006 9 8TX/1FX SM

RSB20-0900S2TTSAABE 942 014 022 9 8TX/1FX SM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900S2TTTAABE 942 014 030 9 8TX/1FX SM E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900S2TTTAAB 942 014 014 9 8TX/1FX SM EEC

Singlemode/Multimode (Copper & Fiber) of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RSB20-0900VVM2SAAB 942 014 008 9 6TX/2FX SM/1 FX MM

RSB20-0900VVM2SAABE 942 014 024 9 6TX/2FX SM/1 FX MM E, pre-configured multicast filtering for EtherNet/IP

RSB20-0900VVM2TAABE 942 014 032 9 6TX/2FX SM/1 FX MM E, pre-configured multicast filtering for EtherNet/IP

RSB20-0900VVM2TAAB 942 014 016 9 6TX/2FX SM/1 FX MM EEC

SFP of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RSB20-0900ZZZ6SAAB 942 014 004 9 6TX/3SFP

RSB20-0900ZZZ6SAABE 942 014 020 9 6TX/3SFP E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900ZZZ6TAABE 942 014 028 9 6TX/3SFP E, pre-configured multicast filtering for EtherNet/IP use

RSB20-0900ZZZ6TAAB 942 014 012 9 6TX/3SFP EEC

MS20 - All Ports are 10/100 Mbps of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

MS20-0800SAAE 943 435-001 2 x any MM2/MM3 (2 slots, max. 8 x 10/100 Mbps ports)

MS20-0800SAAP 943 435-002 2 x any MM2/MM3 (2 slots, max. 8 x 10/100 Mbps ports)

MS20-0800ECCP 943 956-001 2 x any MM2/MM3 (2 slots, max. 8 x 10/100 Mbps ports), -40 to +70 deg, conformal coated, 24/48 VDC

MS20-1600SAAE 943 435-003 4 x any MM2/MM3 (6 slots max. 16 x 10/100 Mbps ports/24 ports w/ MB-2T)

MS20-1600SAAP 943 435-004 4 x any MM2/MM3 (6 slots max. 16 x 10/100 Mbps ports/24 ports w/ MB-2T)

MS20-1600ECCP 943 956-002 4 x any MM2/MM3 (6 slots max. 16 x 10/100 Mbps ports/24 ports w/ MB-2T), -40 to +70 deg, conformal coated, 24/48 VDC

MS30, 2x 10/100 RJ45 / Gigabit SFP combo ports - All Other Ports are 10/100 Mbps of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

MS30-0802SAAE 943 435-005 2 x any MM2/MM3 and 1 x MM4-2TX/SFP (max 10 ports)

MS30-0802SAAP 943 435-006 2 x any MM2/MM3 and 1 x MM4-2TX/SFP (max 10 ports)

MS30-1602SAAE 943 435-007 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x MM4-2TX/SFP (max 26 ports)

MS30-1602SAAP 943 435-008 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x MM4-2TX/SFP (max 26 ports)

MS Backplane Extensions of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Part No. Order No. Extensions for Use With

MB-2T 943 733-102 MS20-16, MS30-16, and MS4128

MB20-2TAHH 943 435-002 Same as above but with -40°C to +70°C

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

MS4128-L2P 943 009-002 Layer 2/Professional 28 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x any MM4(max 28 ports)

MS4128-L2P EEC 943 009-103 Layer 2/Professional 28 Same as 002 except extended temperature range

MS4128-L3E 943 009-202 Layer 3/Enhanced 28 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x any MM4(max 28 ports)

MS4128-L3E EEC 943 009-203 Layer 3/Enhanced 28 Same as 202 except extended temperature range

MS4128-L3P 943 009-302 Layer 3/Professional 28 4 x any MM2/MM3 (6 x w/MB-2T) and 1 x any MM4(max 28 ports)

MS4128-L3P EEC 943 009-303 Layer 3/Professional 28 Same as 302 except extended temperature range

MS Modules: Maximum Module Density of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

MS20-08 2 x any MM2/MM3

MS20-16 4 x any MM2/MM3 (6 x using MB-2T backplane extension)

MS30-08 2 x any MM2/MM3 plus 1 x MM4-2TX/SFP

MS30-16 4 x any MM2/MM3 (6 x using MB-2T backplane extension), plus 1 x MM4-2TX/SFP

MS4128 4 x any MM2/MM3 (6 x using MB-2T backplane extension), plus 1 x any MM4

MS Modules: ALL COPPER of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

Type Part No. Order No. Ports/Speed

ALL COPPER MM2-4TX1 943 722-101 4 x 10/100 Mbps RJ45

ALL COPPER MM2-4TX1-EEC 943 722-151 4 x 10/100 Mbps RJ45, ext. temperature range*

MS Managed Modular DIN Rail Mount Switches of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

MS Modules: MULTIMODE of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

MM MM2-2FXM2 943 718-101 2 x 100 Mbps MM SC

MM MM3-4FXM2 943 764-101 4 x 100 Mbps MM SC

MM MM3-4FXM4 943 835-101 4 x 100 Mbps MM ST

MM MM3-1FXM2/3TX1 943 839-101 1 x 100 Mbps MM SC, 3 x RJ45

MM MM3-2FXM4/2TX1 943 837-101 2 x 100 Mbps MM ST, 2 x RJ45

MM MM3-4FLM4 943 760-101 4 x 10 Mbps MM ST

MM MM3-2FXM2/2TX1 943 761-101 2 x 100 Mbps MM SC, 2 x RJ45

MM MM3-2FXM2/2TX1-EEC 943 761-151 2 x 100 Mbps MM SC, 2 x RJ45, ext. temperature range*

MM MM3-1FXM2/1FXS2/2TX1 943 929-101 2 x 100 Mbps SC (1 x MM and 1 x SM), 2 x RJ45

MM MM2-4FXM3 943 721-101 4 x 100 Mbps MM MTRJ

MM MM2-2FXM3/2TX1 943 720-101 2 x 100 Mbps MM MTRJ, 2 x RJ45

SFP MM20-Z6Z6Z6Z6SAHH 943 938-001 4 x 100 Mbps SFP sockets (SFPs need to be purchased separately), for MS20, MS30 and MS4128

MS Modules: SINGLEMODE of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

SM MM 2-2FXS2 943 719-101 2 x 100 Mbps SM SC

SM MM 3-2FXS2/2TX1 943 762-101 2 x 100 Mbps SM SC, 2 x RJ45

SM MM 3-2FXS2/2TX1-EEC 943 762-151 2 x 100 Mbps SM SC, 2 x RJ45, ext. temp.*

SM MM 3-1FXS2/3TX1 943 838-101 1 x 100 Mbps SM SC, 3 x RJ45

SM MM 3-4FXS2 943 836-101 4 x 100 Mbps SM SC

SM MM 3-1FXL2/3TX1 943 763-101 1 x 100 Mbps SM, SC Long Haul, 3 x RJ45

SM MM3-1FXLH+/3TX1 943 930-101 1 x 100 Mbps SM SC Long Haul+, 3 x RJ45

SM MM 3-1FXS2/3TX1-EEC 943 838-151 1 x 100 Mbps SM SC, 3 x RJ45, ext. temp.*

SFP MM20-Z6Z6Z6Z6SAHH 943 938-001 4 x 100 Mbps SFP sockets (SFPs need to be purchased separately), for MS20, MS30 and MS4128

MS Modules: GIGABIT of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

GIGABIT MM 4-2TX/SFP 943 622-001 2 x Gigabit RJ45/SFP combo ports** for use with MS30 and MS4128

GIGABIT MM 4-4TX/SFP 943 010-001 4 x Gigabit RJ45/SFP combo ports** for use with MS4128 only

MS Modules: SPECIAL PURPOSE of Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

REALTIME MM23-T1T1T1T1SA PTP IEEE1588 Version 2 realtime module, 4x 10/100 RJ45, replacement for 943 117-001

REALTIME MM23-M2M2T1T1SA PTP IEEE1588 Version 2 realtime module, 2x multimode, SC sockets, replacement for 943 117-002

REALTIME MM23-S2S2T1T1SA PTP IEEE1588 Version 2 realtime module, 2x singlemode, SC sockets, replacement for 943 117-003

REALTIME MM23-F4F4T1T1SA PTP IEEE1588 Version 2 realtime module, 2x multimode, ST sockets, replacement for 943 117-004

REALTIME MM33-O7O79999SA PTP IEEE1588 Version 2 realtime module, SFP sockets

REALTIME MM3-4TX1-RT-EEC 943 955-001 4 x RJ45, railway certifications EN 50155, EN 50121-4

REALTIME MM3-2FXM2/2TX1-RT-EEC 943 955-002 2 x 100 Mbps MM SC, 2 x RJ45, IEEE 1588, railway certifications EN 50155, EN 50121-4

REALTIME MM3-2FXS2/2TX1-RT-EEC 943 955-003 2 x 100 Mbps SM SC, 2 x RJ 45, IEEE 1588, railway certifications EN 50155, EN 50121-4

AUI MM3-2AUI 943 840-101 2 x AUI SUB-D 15-pin male D-sub

IP67 MM3-4TX5 943 841-101 4 x M12 socket (D-code), for connectors see OCTOPUS family

POE MM22-T1T1T1T1SAHH 943 938-002 4 x RJ45 PoE (external PoE power supply)

SFP MM20-Z6Z6Z6Z6SAHH 943 938-001 4 x 100 Mbps SFP sockets (SFPs need to be purchased separately), for MS20, MS30 and MS4128

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400T1T1SDAE   RS20-0400T1T1SDAP   RS20-0400M2T1SDAE   RS20-0400M2T1SDAP    RS20-0400M2M2SDAE

RS20-0400M2M2SDAP  RS20-0800T1T1SDAE   RS20-0800T1T1SDAP   RS20-0800M2M2SDAE    RS20-0800M2M2SDAP

RS20-0800M2M2SDHE  RS20-0800M4M4SDAE  RS20-0800M4M4SDAP   RS20-0800M4M4SDHP   RS20-1600M2T1SDAE

RS20-1600M2T1SDAP   RS20-1600M2M2SDAE  RS20-1600M2M2SDAP   RS20-1600T1T1SDAE    RS20-1600T1T1SDAP

RS20-2400M2M2SDAE   RS20-2400M2M2SDAP   RS20-2400T1T1SDAE   RS20-2400T1T1SDAP   OCTOPUS 16M-2FX

OCTOPUS 24M-2FX

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400T1T1SDAE   RS20-0400T1T1SDAP    RS20-0400M2T1SDAE   RS20-0400M2T1SDAP  RS20-0400M2M2SDAE

RS20-0400M2M2SDAP   RS20-0800T1T1SDAE   RS20-0800T1T1SDAP   RS20-0800M2M2SDAE  RS20-0800M2M2SDAP

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-1600M2T1SDAP  RS20-1600M2M2SDAE  RS20-1600M2M2SDAP  RS20-1600T1T1SDAE   RS20-1600T1T1SDAP

RS20-2400M2M2SDAE  RS20-2400M2M2SDAP  RS20-2400T1T1SDAE  RS20-2400T1T1SDAP  OCTOPUS 16M-2FX  OCTOPUS 24M-2FX

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400T1T1SDAEHC       RS20-0400T1T1SDAPHC       RS20-0800T1T1SDAEHC        RS20-0800T1T1SDAPHC

RS20-1600T1T1SDAEHC      RS20-1600T1T1SDAPHC        RS20-2400T1T1SDAEHC        RS20-2400T1T1SDAPHC

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400M2T1SDAEHC     RS20-0400M2T1SDAPHC   RS20-0400M2M2SDAEHC   RS20-0400M2M2SDAPHC  RS20-0800M2M2SDAEHC

RS20-0800M2M2SDAPHC    RS20-0800M4M4SDAEHC   RS20-0800M4M4SDAPHC   RS20-1600M2T1SDAEHC   RS20-1600M2T1SDAPHC

RS20-1600M2M2SDAEHC    RS20-1600M2M2SDAPHC   RS20-2400M2M2SDAEHC   RS20-2400M2M2SDAPHC

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

RS20-0400S2T1SDAEHC     RS20-0400S2T1SDAPHC   RS20-0400S2S2SDAEHC    RS20-0400S2S2SDAPHC    RS20-0800S2S2SDAEHC

RS20-0800S2S2SDAPHC    RS20-1600S2S2SDAEHC   RS20-1600S2S2SDAPHC   RS20-2400S2S2SDAEHC     RS20-2400S2S2SDAPHC

Hirschmann RS30-1602OOZZSDAE Rail Switches RS30-1602OOZZSDAE Gigabit Ethernet Switch Arrived

We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.

We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.

Contact:

HONGKONG XIEYUAN TECH CO., LIMITED

Email:becky@hkxytech.com   Web:www.hkxytech.com

Mobile:+86-15972186287(Whatsapp & Wechat)
