Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived

News December 10, 2020

Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived



Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Features of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Strain Gauge Converter KFD2-WAC2-Ex1.D

1-channel isolated barrier

24 V DC supply (Power Rail)

Strain gauge input (full or half bridge)

Output 0 mA ... ± 20 mA or 0 V ... ± 10 V

2 relay contact outputs

Programmable high/low alarm

Configurable by PACTware or keypad

RS-485 interface

Line fault detection (LFD)



Function of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


This isolated barrier is used for intrinsic safety applications.

The device is used with strain gauges, load cells and resistance measuring bridges.

Designed to provide 5 V excitation voltage, this barrier’s high quality A/D converter allows it to be used with those devices requiring 10 V.

Up to four 350 Ω strain gauges connected in parallel may be powered and evaluated.

The device is easily configured by the use of keypad or with the PACTware configuration software.

The current measurement for tare, zero point, and final value can be entered in this manner.

A fault is signalized by LEDs and a separate collective error message output.



Technical data of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Product Description of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


24 V DC



General specifications of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Signal type Analog input


Supply of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Connection Power Rail or terminals 23+, 24-

Rated voltage 20 ... 35 V DC

Ripple within the supply tolerance

Power consumption max. 3 W


Interface of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Connection Power Rail or terminals 19+, 20 GND, 21-

Type RS-485

Programming interface programming socket


Field circuit of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Connection terminals 1+, 2-, 3+, 4-, 5+, 6-

Lead resistance max. 25 Ω per line

Input I

Connection terminals 1+, 2-

Sensor supply 1 ... 5 V

Connection terminals 3+, 4- (supply); 5+, 6- (signal)

Short-circuit current 50 mA

Load ≥ 116 Ω up to 5V, ≥ 85 Ω up to 4V


Input of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Connection side field side

Connection Input I: terminals 1+, 2-; Input II: terminals 13+, 14-; Input III: terminals 15+, 14-

Programmable Tare 0 ... 500 % of span

Input I Signal, analog

Input signal -100 ... 100 mV

Input resistance > 1 MΩ for voltage measurement

Input II, III tare adjustment, calibration and zero

Open circuit voltage/short-circuit current 18 V / 5 mA

Active/Passive I > 4 mA/I < 1.5 mA


Output of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Connection side control side

Connection Output I: terminals 10, 11, 12; Output II: terminals 16, 17, 18; Output III: terminals 7-, 8+, 9-

Output I, II Relay output

Contact loading 253 V AC/2 A/500 VA/cos φ min. 0.7; 40 V DC/2 A resistive load

Mechanical life 2 x 107 switching cycles

Output III Analog output

Current range -20 ... 20 mA

Load max. 550 Ω

Analog voltage output 0 ... ± 10 V; output resistance 500 Ω (bridge between terminal 7 and 9)

Analog current output 0 ... ± 20 mA or 4 ... 20 mA; load 0 ... 550 Ω (terminals 7 and 8)

Line fault detection downscale -21.5 mA (-10.75 V) or 2 mA (1 V), upscale 21.5 mA (10.75 V)

Collective error message Power Rail


Transfer characteristics of Pepperl+Fuchs KFD2-WAC2-Ex1.D Strain Gauge Converter KFD2-WAC2-Ex1.D Isolated Barriers


Deviation

Resolution/accuracy ≤ ± 0.05 % incl. non-linearity and hysteresis

Temperature effect ≤ ± 0.01 %/K

Reaction time 300 ... 850 ms



Galvanic isolation of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Input I/other circuits reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff

Output I, II against eachother reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff

Output I, II/other circuits reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 Veff

Output III/Input II, III not available

Output III/Programming socket not available

Other circuits from each other functional insulation, rated insulation voltage 50 Veff



Indicators/settings of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Display elements LEDs , display

Control elements Control panel

Configuration via operating buttons

via PACTware

Labeling space for labeling at the front


Directive conformity of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Electromagnetic compatibility

Directive 2014/30/EU EN 61326-1:2013 (industrial locations)

Low voltage

Directive 2014/35/EU EN 61010-1:2010



Conformity of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Electromagnetic compatibility NE 21:2006

Degree of protection IEC 60529:2001



Ambient conditions of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Ambient temperature -20 ... 60 °C (-4 ... 140 °F)



Mechanical specifications of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Degree of protection IP20

Connection screw terminals

Mass approx. 250 g

Dimensions 40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch) , housing type C3

Mounting on 35 mm DIN mounting rail acc. to EN 60715:2001


Accessories of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


DTM Interface

Technology

PACTware 5.X FDT Framework

KFD2-EB2 Power Feed Module

KFD2-EB2.R4A.B Power feed module, redundant supply

KFD2-EB2.R4A.B.SP Power feed module with spring terminals, redundant supply

KFD2-EB2.SP Power feed module with spring terminals

UPR-05 Universal Power Rail with end caps and cover, 5 conductors, length: 2 m

UPR-05-S Universal Power Rail with end caps and cover, 5 conductors, length: 0.8 m

K-DUCT-BU

K-DUCT-BU-UPR-05 Profile rail with UPR-05- * insert, 5 conductors, wiring comb field side blue

K-ADP-USB


Application of Pepperl+Fuchs KFD2-WAC2-Ex1.D Intrinsic Safety Barriers KFD2-WAC2-Ex1.D Strain Gauge Converter Arrived


Single or parallel connection of strain gauges with resulting resistance between 116  ... 10 k can be connected and will

provide a 4 mA ... 20 mA output and 2 relay outputs as well as an RS 485 interface in the safe area.


The device supports the transmission of measured values via the RS 485 interface. In this mode of operation, input signal range

may be transmitted with 26 Bit resolution with up to 31 signal converters connected to the Power Rail UPR-05 or via terminals 19,20 and 21.


RS 485 communication may be done via the Power Rail when using power feed modules with bus access, e. g. KFD2-

EB2.R4A.B or via the terminals 19, 20 and 21 of one module. The device is addressed via keypad and display or with a PC with

PACTware and adapter K-ADP-USB.
