Emerson SP2401 Unidrive SP AC Drives SP2401 Variable Frequency Drives
Details of Emerson SP2401 Unidrive SP AC Drives SP2401 Variable Frequency Drives
The SP2401 is a high performance drive module for system integration and stand alone applications. Due to the inherent performance and flexibility of the SP2401, potential areas for its application are limitless. The variable frequency drives’ intelligence and dynamic response allow it to be applied in the most demanding applications. Typical applications include: high speed machines, crane and hoist, lift and elevator controls, pulp and paper machines, metal production and processing, materials handling systems, marine applications, printing, textile machines, converting, energy saving with fans and pumps, plastics and rubber extrusion machines, and more.
Description of Emerson SP2401 Unidrive SP AC Drives SP2401 Variable Frequency Drives
Control Techniques' Unidrive SP Panel Mount are standard AC input, AC output drives for installation within a control panel. The drives are easy to install and commission and can be applied in a wide range of applications including as an Open loop V/Hz AC Drive, an Open loop Vector AC Drive or even an Open Loop Rotor Flux Control (RFC). The Unidrive SP truly boasts a vast range of system integration features. Control Techniques Part Reference: SP2401
CONTROL TECHNIQUES SP2401 - 15.3A OUTPUT CURRENT (NORMAL DUTY), 400V DRIVE RATING, UNIDRIVE SP AC DRIVE
Part Number: SP2401
Technical information of Emerson SP2401 Unidrive SP AC Drives SP2401 Variable Frequency Drives
Unidrive SP Panel Mounted
Part Number: SP2401
Manufacturer: Control Techniques
Product Type: Unidrive SP Panel Mounted AC Drive
Maximum Continuous Output Current (Normal Duty): 15.3A
Nominal Power at 400V (Normal Duty): 7.5kW
Maximum Continuous Output Current (Heavy Duty): 13A
Nominal Power at 400V (Heavy Duty): 5.5kW
Model Size: 2
OVERVIEW of Emerson SP2401 Unidrive SP AC Drives SP2401 Variable Frequency Drives
Unidrive SP AC/Servo Drive
SPECIFICATIONS of Emerson SP2401 Unidrive SP AC Drives SP2401 Variable Frequency Drives
Drive Type Servo, Variable Frequency
Number of Input Phases 3
Drive Supply Voltage 380/480 V ac
Horsepower Rating Normal Duty 10 hp
Output Current Normal Duty 15.3 A
Operation Mode Open Loop Vector Control, V/Hz Control, Closed Loop Induction Motor Control, Regenerative Control, Servo Control, Rotor Flux Control
Enclosure Rating IP 20
Motor Phase 3 ph
Horsepower Rating Heavy Duty 7-1/2 hp
Output Current Heavy Duty 13 A
Peak Current 22.7 A
Peak Current Normal Duty 16.8 A
Peak Current Heavy Duty 22.7 A
Input Frequency Rating 50/60 Hz
Overall Depth 219 mm
Overall Dimensions (Height x Width x Depth) 15.3 in x 6.1 in x 8.9 in
Overall Height 368 mm
Overall Width 155 mm
Ambient Temperature Range 32 to 104 °F
Maximum Ambient Temperature 104 °F
Minimum Ambient Temperature 32 °F
Operating Temperature Range +32 to +122 °F
Standard Operating Temperature Range 32 to +104 °F
Number of Analog Inputs 3
Number of Digital Inputs 3
Number of Safety Inputs - STO 1
Configurable Digital Inputs/Outputs 3
Number of Analog Outputs 2
Number of Digital Outputs 1
Number of Relays 1
Feedback Type Incremental Encoder, Absolute Encoder
PLC Functions Onboard PLC
Dynamic Braking Dynamic Braking Transistor
Keypad / Display Option SM-Keypad
PI / PID Controller PID Controller
Serial Communication Onboard Modbus RTU
Pulse Train Input Capability Yes
Pulse Train Output Capability Yes
Mounting Type Surface, Through-panel
Number of Option Slots 3
Compatible Accessories Backup, Communications, I/O, Feedback, Automation
Serial Communication Options CANOpen, DeviceNet, EtherNet/IP, Modbus TCP/IP, EtherCAT, PROFIBUS DP
Backup Option Cards SMARTCARD
Communications Option Cards SM-CAN, SM-CANOPEN, SM-DEVICENET, SM-ETHERCAT, SM-ETHERNET, SM-INTERBUS, SM-PROFIBUS-DP, SM-PROFINET, SM-SERCOS
I/O Option Cards SM-I/O-32, SM-I/O-120V, SM-I/O-24V, SM-I/O-LITE,SM-I/O-PELV, SM-I/O-PLUS, SM-I/O-TIMER
Feedback Option Cards SM-ENCODER-OUT, SM-ENCODER-PLUS, SM-RESOLVER, SM-UNI-ENCODER
Automation Option Cards SM-APPS-LITE-V2, SM-APPS-PLUS, SM-REGISTER, SM-EZMOTION
Encoder Connection Standard
Remote Keypad SM-KEYPAD-PLUS
Typical Application Fans, Pumps, Conveyors, Compressors, Extruders, Winders, Hoists, Packaging, Printing, Cutting
Series Unidrive SP
Weight 15.4 lbs
Warranty 1 Year
Agency Listing cULus File E171230
Standards Met UL508C, EN 61800-5-1:2007, EN 61800-3:2004, EN 61000-6-2:2005, EN 61000-6-4:2007, EN 61000-3-2:2006, EN 61000-3-3:2008
Ordering Models of Emerson SP2401 Unidrive SP AC Drives SP2401 Variable Frequency Drives
