MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
Description of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL5510 (4-channel, digital input) controlled by up to four switches or proximity detectors located in terminal and can switch +ve or –ve polarity signals. A range of module configurations is available (see Table 1) through the use of selector switches. When proximity detector modes are selected, LFD is enabled and the output switches to OFF if a line fault is detected.
Specification of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
See also common specification number of channels
4, configured by switches
Location of switches
Zone 0, IIC, T6 hazardous area
Div 1, Group A hazardous location
Location of proximity detectors
Zone 0, IIC, T4-6 hazardous area if suitably certified
Div 1, Group A, hazardous location
Hazardous-area inputs
Inputs conforming to BS EN60947–5–6:2001 standards for proximity detectors (NAMUR)
Voltage applied to sensor
7 to 9V dc from 1kΩ ±10%
Input/output characteristics
Normal phase
Outputs closed if input > 2.1mA (< 2kΩ in input circuit) Outputs open if input < 1.2mA (> 10kΩ in input circuit)
Hysteresis: 200µA (650Ω) nominal
Line fault detection (LFD) (when selected)
User-selectable via switches on the side of the unit. Open-circuit alarm on if Iin < 50µA
Open-circuit alarm off if Iin > 250µA
Short-circuit alarm on if Rin < 100Ω
Short-circuit alarm off if Rin > 360Ω
Note: Resistors must be fitted when using the LFD facility with a contact input
500Ω to 1kΩ in series with switch
20kΩ to 25kΩ in parallel with switch
Safe-area outputs
Floating solid-state outputs compatible with logic circuits
Operating frequency: dc to 500Hz
Max. off-state voltage: ± 35V Max. off-state leakage current: ± 50µA
Max. on-state resistance: 25Ω Max. on-state current: ± 50mA
LED indicators
Green: power indication
Yellow: four: on when output active
Red: LFD indication + faulty channel’s yellow LED flashes
Maximum current consumption
40mA at 24V (with all output channels energised)
Power dissipation within unit
0.96W at 24V, with 10mA loads
Safety description (each channel)
Uo=10.5V Io=14mA Po=37mW Um = 253V rms or dc
PRODUCT LITERATURE of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
Product CodeDescription
intrinsically safe logo Symbol denotes that the equipment is suitable for use in hazardous area applications.
fsm logo Symbol denotes that the product has been assessed for functional safety applications.
SM45-55-AI SM45-55-AI is FSMFSM Safety Manual - Analogue Input Modules
SM45-55-AO SM45-55-AO is FSMFSM Safety Manual - Analogue Output Modules
SM45-55-BI SM45-55-BI is FSMFSM Safety Manual - Binary Input Modules
SM45-55-MMI SM45-55-MMI is FSMFSM Safety Manual - Machine Monitor Interfaces
SM45-55-SAD SM45-55-SAD is FSMFSM Safety Manual - Solenoid / Alarm Driver Modules
1. Intro of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
INA4500MTL4500/4600 range Instructions for Safe Use
INM4500/4600MTL4500/4600 range Instruction Manual
MTL4500-5500-ACCBackplanes, Enclosures & Accessories
MTL4500-5500-CSCommon Specifications
MTL4500-5500-DSMTL4500-5500 range Data Set
2. Digital Input of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4501-SR MTL4501-SR is intrinsically safe MTL4501-SR is FSM1ch DI failsafe solid-state output + LFD alarm
MTL4504 MTL4504 is intrinsically safe MTL4504 is FSM1ch DI relay output + LFD alarm + phase reversal
MTL4510 MTL4510 is intrinsically safe4ch DI solid-state output
MTL4510B MTL4510B is intrinsically safe4ch DI multifunction solid-state output
MTL4511 MTL4511 is intrinsically safe MTL4511 is FSM1ch DI relay output
MTL4513 MTL4513 is intrinsically safe2ch DI solid-state output
MTL4514D MTL4514D is intrinsically safe MTL4514D is FSM1ch switch/prox input, dual output relay
MTL4514_B MTL4514_B is intrinsically safe MTL4514_B is FSM1ch DI relay output + LFD alarm
MTL4516 MTL4516 is intrinsically safe MTL4516 is FSM2ch DI relay output
MTL4516C MTL4516C is intrinsically safe MTL4516C is FSM2ch DI with changeover relay output
MTL4517 MTL4517 is intrinsically safe MTL4517 is FSM2ch DI relay output + LFD alarm
3. Digital Output of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4521 MTL4521 is intrinsically safe MTL4521 is FSMLoop powered solenoid driver
MTL4521L MTL4521L is intrinsically safe MTL4521L is FSMloop powered solenoid driver IIC
MTL4523 MTL4523 is intrinsically safe MTL4523 is FSMSolenoid driver with LFD
MTL4523L MTL4523L is intrinsically safe MTL4523L is FSMLoop powered solenoid driver + LFD
MTL4523R MTL4523R is intrinsically safe MTL4523R is FSMSolenoid driver with LFD
MTL4523V-VL MTL4523V-VL is intrinsically safe MTL4523V-VL is FSMSolenoid/Alarm driver with voltage control
MTL4524 MTL4524 is intrinsically safe MTL4524 is FSMSwitch operated solenoid driver
MTL4524S MTL4524S is intrinsically safe MTL4524S is FSMSwitch operated solenoid driver, 24V override
MTL4525 MTL4525 is intrinsically safe MTL4525 is FSMSwitch operated solenoid driver low power
MTL4526 MTL4526 is intrinsically safe2ch switch operated relay
4. Analogue Input of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4541 MTL4541 is intrinsically safe MTL4541 is FSM1ch 2/3 wire Transmitter repeater
MTL4541A MTL4541A is intrinsically safe1ch Transmitter repeater, passive input
MTL4541AS MTL4541AS is intrinsically safe1ch Transmitter repeater, passive input, current sink
MTL4541B MTL4541B is intrinsically safe MTL4541B is FSMMTL4041B replacement
MTL4541P MTL4541P is intrinsically safeMTL4041P replacement
MTL4541S MTL4541S is intrinsically safe MTL4541S is FSM1ch 2/3 wire Transmitter repeater, current sink
MTL4541T MTL4541T is intrinsically safe2/3 wire Transmitter repeater
MTL4544 MTL4544 is intrinsically safe MTL4544 is FSM2ch 2/3 wire Transmitter repeater
MTL4544A MTL4544A is intrinsically safe2ch Transmitter repeater, passive input
MTL4544AS MTL4544AS is intrinsically safe2ch Transmitter repeater, passive input, current sink
MTL4544B MTL4544B is intrinsically safeMTL4044 replacement
MTL4544D MTL4544D is intrinsically safe MTL4544D is FSM2/3 wire transmitter repeater, dual output
MTL4544S MTL4544S is intrinsically safe MTL4544S is FSM2ch 2/3 transmitter repeater, current sink
5. Analogue Output of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4546 MTL4546 is intrinsically safe MTL4546 is FSM1ch 4-20mA smart isolating driver + LFD
MTL4546C MTL4546C is intrinsically safe MTL4546C is FSM1ch 4-20mA smart isolating driver + oc LFD
MTL4546S MTL4546S is intrinsically safe1ch 4-20mA HART isolating driver + LFD
MTL4546Y MTL4546Y is intrinsically safe MTL4546Y is FSM1ch 4-20mA smart isolating driver + oc LFD
MTL4549 MTL4549 is intrinsically safe MTL4549 is FSM2ch 4-20mA smart isolating driver + LFD
MTL4549C MTL4549C is intrinsically safe MTL4549C is FSM2ch 4-20mA smart isolating driver + oc LFD
MTL4549Y MTL4549Y is intrinsically safe MTL4549Y is FSM2ch 4-20mA smart isolating driver + oc LFD
6. Temperature Input of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4573 MTL4573 is intrinsically safe1ch Temperature converter, RTD / THC
MTL4575 MTL4575 is intrinsically safe1ch Temperature converter, RTD / THC with alarm
MTL4576-RTD MTL4576-RTD is intrinsically safe2ch Temperature converter, RTD
MTL4576-THC MTL4576-THC is intrinsically safe2ch Temperature converter, THC
MTL4581 MTL4581 is intrinsically safe1ch mV/THC isolator for low-level signals
MTL4582B MTL4582B is intrinsically safe MTL4582B is FSM1ch resistance isolator to repeat RTD signals
7. Pulse and Vibration of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4531 MTL4531 is intrinsically safe MTL4531 is FSM1ch vibration probe interface
MTL4532 MTL4532 is intrinsically safe1ch pulse isolator, digital or analogue output
8. Fire and Smoke of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4561 MTL4561 is intrinsically safe MTL4561 is FSM2ch loop-powered, for fire and smoke detectors
9. General of MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL4599Dummy isolator
MTL4599NGeneral purpose feed-through module
MTL5510 Safety Barriers MTL5510 Switch / Proximity Detector Interface In Stock
MTL5000FunctionMTL5500Notes
MTL5011B1ch, changeover relay outputMTL5511
MTL50121ch, solid-state output
Use 1ch of MTL5513
MTL5012S1ch, solid-state output, UE1 special
No replacement
MTL50141ch, c/o relay output, LFD relayMTL5514/14DMTL5514 does not provide 1in 2out
function. MTL5514D with 1in 2out
available Q1 2014
MTL50152ch, solid-state outputMTL5513Common connection on haz side,
max frequency response 500Hz
MTL50162ch, n/o relay outputMTL5516C
MTL50172ch, n/o relay output, LFD relayMTL5517LFD relay energises on alarm
MTL50182ch, changeover relay outputMTL5516CCommon connection on haz side
MTL5018ac2ch, changeover relay output, ac power
Continues as MTL5018ac.
Alternative option: MTL5516C fitted
with MPA5500 ac adaptor
MTL5021Loop powered, IIC, (12.85V, 45mA, cl 45mA)MTL5521(12.8V, 48mA, cl 48mA)
MTL5022Loop powered, IIB, (12.9V, 60mA, cl 60mA)MTL5522(9.9V, 70mA, cl 70mA)
MTL5023Logic ctrl, lfd, phase,(12.85V, 45mA, cl 45mA)MTL5523(12.8V, 48mA, cl 48mA)
MTL5024Logic ctrl, phase, (12.85V, 45mA, cl 45mA)MTL5524(12.8V, 48mA, cl 48mA)
MTL5025Loop powered, IIC, (8.6V, 45mA, cl 45mA)MTL5525(7V, 48mA, cl 48mA), lower Io
MTL5031Vibration transducer interfaceMTL5531Now Velomitor compatible
MTL5032Pulse isolatorMTL5532Now with 4-20mA output and alarm
MTL5040Loop isolator
Use MTL5541 and MTL5546Y
MTL5041For 2-wire transmittersMTL5541
MTL5042For 2- or 3-wire txs, smartMTL5541
MTL5043Dual output for 2-wire smart txsMTL5544DNo current sink o/p. Passive Tx input
MTL5044Two channel for 2-wire txsMTL5544Now with passive Tx inputs
MTL5045Isolating driverMTL5546YSmart only versions
MTL5046Smart isolating driver with LFDMTL5546
MTL5049Two channel isolating driverMTL5549YSmart only versions
MTL5051Serial-data comms isolator
Continues as MTL5051 model
MTL5053Fieldbus isolator/power supply
Discontinued
MTL5061Fire/smoke detector interfaceMTL5561
MTL5073Temperature converterMTL5575Now with trip alarm
MTL5074Temperature converterMTL5575Now with trip alarm
MTL5081mV/THC isolatorMTL5581
MTL5082Resistance isolatorMTL5582
MTL5113PFailsafe sw/prox interfaceMTL5501-SR
MTL5314Trip amplifier
Continues as MTL5314 model
MTL5344Repeater power supply
Discontinued
MTL5349Isolating driver
Discontinued
MTL599124V power supply
Continues as MTL5991 model
MTL5995Fieldbus power supply
Convert to F10X range product
